Fuel Pre Filter Element
Product NO.:K1006530\K1006529\400508-00118\400508-00119\400508-00062\400508-00063
K1006530
Size/Dimension:110X150
Net Weight:0.922KG
K1006529
Size/Dimension:110X230
Net Weight:1.156KG
400508-00062
Size/Dimension:Ø109X143
Net Weight:0.8KG
The main function of the excavator fuel pre-filter element is to block particles, water, and impurities in the fuel, ensuring that the precision components of the fuel system are protected from wear and other damage.
Fuel filters, including diesel filters, gasoline filters, and natural gas filters, are indispensable components of the fuel system. Their primary function is to remove impurities, moisture, and gums from the fuel, ensuring that the fuel supplied to the engine is clean and preventing contaminants from entering the engine, which could cause wear or blockages in precision components. For excavators, the role of the fuel filter is equally important, as it protects the engine and hydraulic system from performance degradation or damage caused by impurities, moisture, and gums in the fuel.
Specifically, the functions of the excavator fuel pre-filter element include, but are not limited to:
1. Protecting the Engine: By filtering out particles, moisture, and impurities from the fuel, it prevents these contaminants from entering the engine, thereby protecting it from wear and other damage.
2. Ensuring Normal Operation of the Fuel System: By providing clean fuel, it ensures that precision components of the fuel system, such as fuel injectors and fuel pumps, can operate normally, avoiding performance degradation or failures caused by blockages from impurities.
3. Improving Engine Efficiency: By filtering out contaminants, it ensures that the engine receives pure fuel, thus enhancing the engine’s working efficiency and power output.
In summary, the excavator fuel pre-filter element plays a crucial role in protecting the engine, ensuring the normal operation of the fuel system, and improving engine efficiency.
| Product NO. | Applicable models | Weight | Packaging unit
|
| K1006530 | DH150W-7S
DH210W-7S DH215-9 DH215-9E DH220LC-9E DH225LC-9 DH370LC-7 DX150LC DX150LCS DX225LC DX230LC-SKD DX230LCS DX260LC DX140 DX140A DX140LC DX140LC-3 / DX160LC-3 DX140LCR DX140LCR-3 DX140R DX140W / DX160W TIER-III DX140W ACE DX140W TIER-III DX140W-3 / DX160W-3 DX140WA DX170W DX180LC DX180LC-3 DX190W DX190W-3 DX210W DX210WA DX220A / DX225LCA DX220AF DX220LC (TIER-3) DX220LCA DX225LC DX225LC (S/N 5433~) DX225LC-3 DX225NLC DX230LC DX235LCR DX255LC DX255LC-3 DX420LC-3 DX490LC-3 DX530LC-3 TXC140LC-2 TXC180LC-2 TXC225LC-2 TXC255LC-2 DX140LC DX140LC-3 DX140W-3 / DX160W-3 DX140W/DX160W DX160LC DX160LC-3 DX160W RAIL WAY DX180LC DX180LC-3 DX225LC DX225LC-3 DX235NLC DX255LC DX255LC-3 |
0.922 KG | EA |
| K1006529 | DH370LC-7
DH370LC-9 DH500LC-7 DX300LC DX300LCS DX345LC DX350LC DX380LC DX420LC DX500LC/DX500LCG DX700LC DX300LC DX300LC-3 DX300LC-3(S/N:1001~1511) DX300LCA DX340LC DX340LC-3 / DX350LC-3 DX340LCA DX350LC DX350LCA / DX360LCA DX360LCA(S/N:5950~) DX380LC DX380LC-3 DX380LC-3(OCEANIA) DX380LCA DX420LC DX420LCA DX480LC DX480LCA / DX500LCA DX480LCA / DX500LCA / DX520LCA DX520LC DX520LC / DX520LCA DX520LCA DX700LC DX700LCA SOLAR 470LC-V SOLAR 500LC-V TXC300LC-2 TXC340LC-2 TXC420LC-2 TXC480LC-2 TXC520LC-2 DX300LC DX300LC-3 |
1.156 KG | EA |
| 400508-00118 | DX125W-10/DX125W-10N
DX125W-9C/DX125W-9CN DX130-10/DX130-10N DX140AF/DX140LCA DX150-9C/DX150LC-9C/DX150LC-9CN DX150LC-10/DX150LC-10N DX150W-7B DX150W-9C/DX150W-9CN DX150WE-9C/DX150WE-9CN DX215-9C ACE/DX215-9CN ACE DX220LC-7M DX220LC-9C ACE DX230LC-9C DX245LC-9C ACE DX270LC-9C ACE DX140LC-7 / DX160LC-7 DX140LC-7K / DX160LC-7K DX140LCR-7 DX150LC-7 DX150LC-7(S/N:2001~) DX150LCR-7 DX170LC-7 DX200A DX220A / DX225LCA DX220AF DX220AF-7M DX225LC-7M / DX225-7M DX225LCA-7M/DX200A-7M E145-7 |
0.922 KG | EA |
| 400508-00119 | DX150W-10/DX150W-10N
DX210W-10/DX210W-10N DX215-10/DX215-10N DX225-10 DX225LC-10 DX245HD-10 DX270HD-10 DX300LC-7B DX305HD-10 DX305LC-9C ACE DX140W-7 / DX160W-7 DX150W-7 / DX170W-7 DX170W-7 DX190W-7 DX210-7 / DX210LC-7 / DX210NLC-7 DX210W-7 DX220W-7 DX225LC-7 DX225LC-7X DX235LC-7 / DX245NHD-7 DX235LCR-7 DX240LC-7 DX240LC-7X DX240LCR-7 DX255LC-7 DX300LC-7 DX300LC-7K DX300LC-7M / DX320LC-7M DX300LCA DX300LCA-7M DX320LC-7 DX340LCA-K/ DX360LCA-K(S/N:20001~) DX350LC-7 DX350LC-7K DX350LCR-7 DX360LC-7M DX360LCA-7M DX400LC-7M DX450LC-7M DX450LCA-7M DX480LCA-K/ DX520LCA-K(S/N:20001~) DX490LC-7M / DX530LC-7M DX490LCA-7M / DX530LCA-7M DX650LC-7 HX355ALCR |
0.941 KG | EA |
| 400508-00062 | DX120
DX140AF/DX140LCA DX150-9C/DX150LC-9C/DX150LC-9CN DX150W(S2) DX150W-9C/DX150W-9CN DX210-7M DX210W-7B DX210W-9C (S/N:30001~) DX210W-9C/DX210W-9CN DX215-5B DX215-9C ACE/DX215-9CN ACE DX215-9C/DX215-9CN DX220LC-7M DX220LC-9C DX220LC-9C ACE DX225CD-9C DX225LC-9C DX230LC-9C DX260LC-9C DX270LC-9C ACE DX140A DX140LC DX140LC-3 / DX160LC-3 DX140LCR DX140LCR-3 DX140R DX140W / DX160W TIER-III DX140W ACE DX140W ACE PLUS(S/N:8141~) DX140W-3 / DX160W-3 DX140W-5 DX140W-5 / DX160W-5 DX140W-5K(L)/ DX160W-5K(L)(S/N:2485~) DX170W DX170W-5 DX180LC DX180LC-3 DX190W DX190W-3 DX190W-5 DX190WA(T-2) DX200A DX200A(S/N:1001~) DX210W DX210W-5 DX210W-5B DX210W-5K(L) DX210WA DX210WA(T-2) DX220A / DX225LCA DX220AF DX220AF(S/N:1001~) DX220AF-7M DX220LC-5 DX220LC-5K(L) DX220LCA DX225LC (S/N 5433~) DX225LC-3 DX225LC-5 DX225LC-7M / DX225-7M DX225LCA(S/N:1001~) DX225LCA-7M / DX200A-7M DX225NLC DX225NLCA DX230LC DX235LC-5 DX235LCR DX235LCR-5 DX235LCR-5K(L) DX235NLC-5 DX255LC DX255LC-3 DX255LC-5 DX260LCA DX300LC-5 DX300LC-5(S/N:1001~1057) DX300LC-5(S/N:1058~) DX340LC-5/ DX350LC-5(S/N:10001~10049) DX340LC-5/ DX350LC-5(S/N:10050~)DX380LC-5 DX380LC-5 / DX400LC-5 DX380LC-5K(L) DX420LC-3 DX420LC-5(S/N:10001~10010) DX420LC-5(S/N:10011~) DX490LC-3 DX490LC-5 / DX530LC-5 DX490LC-5(S/N:10001~10011) DX490LC-5(S/N:10012~) DX530LC-3 DX530LC-5(NT)(S/N:10001~10024) DX530LC-5(NT)(S/N:10025~) DX530LC-5(S/N:10001~10006) DX530LC-5(S/N:10001~10055) DX530LC-5(S/N:10007~) DX530LC-5(S/N:10056~) DX530LC-5K(L) DX140LC-3 DX140W-3 / DX160W-3 DX160LC-3 DX180LC-3 DX225LC-3 DX255LC-3 |
0.8 KG | EA |
| 400508-00063 | DX1000LC-9C
DX300LC-9C DX340LC-9C DX360LC-3B DX360LC-7 DX360LC-9 DX380-9C ACE DX380LC-9C DX380LC-9C ACE DX400LC-7B DX420LC DX450LC-3B/DX450LC-9C DX490LC-9C/DX500LC-9C/DX520LC-9C DX500-9C ACE/DX500LC-9C ACE/DX560LC-9C ACE DX500LC-9C (S/N:22001~22044) DX500LC-9C ACE/DX560LC-9C ACE (S/N:30001~) DX500LC/DX500LCG DX700LC DX800LC-9C DX1000LC-7 TIER3 DX300LC DX300LC-3 DX300LC-3(S/N:1001~1511) DX300LC-3(S/N:1512~) DX300LC-5(S/N:20001~) DX300LC-5K(L) DX300LC-7K DX300LC-7M / DX320LC-7M DX300LCA DX300LCA-7M DX340LC DX340LC-3 / DX350LC- DX340LC-5 / DX350LC-5(S/N:20001~) DX340LCA DX340LCA-K/ DX360LCA-K(S/N:20001~) DX350LC DX350LC-7K DX350LCA / DX360LCA DX360LC-7M DX360LCA(S/N:5950~) DX360LCA-7M DX380LC DX380LC-3 DX380LC-3(OCEANIA) DX380LCA DX400LC-7M DX420LC DX420LCA DX420LCA-K(S/N:20001~) DX450LC-7M DX450LCA-7M DX480LC DX480LCA / DX500LCA DX480LCA / DX500LCA / DX520LCA DX480LCA-K/ DX520LCA-K(S/N:20001~) DX490LC-7M / DX530LC-7M DX490LCA-7M / DX530LCA-7M DX520LC / DX520LCA DX520LCA DX530LC-5B DX650LC-7 DX700LC DX700LCA DX800LC-5B HX1000L HX800L |
1.05 KG | EA |
